NETRA-FLIGHT CAMERAS
Ruggedised camera for Space-Missiles and Airborne Application
Tech Spec
The Netra is small ruggedized color cameras to image dynamic events in harsh environments such as rockets, spacecraft and other remote platforms.
Accessories (optional )
The Netra is small ruggedized color cameras to image dynamic events in harsh environments such as rockets, spacecraft and other remote platforms.
- Netra fairing ( for external application )
- Netra ruggedised recording system (turnkey )
- Netra telemetry transmitter
Additional features
Configurable - using RS 232 adapter/ GigE
Output - composite or HDMI
Lens mount - C type flexibility to mount any lens based on customer need . Dampened space grade mount to reduce vibrations
| Focal Plane | 1/2” color CMOS Sony* |
| Frame rate | 30fps. Pixels, |
| Output | NTSC 768 x 494 (PAL 752 x 582 ) 1080X720 (HDMI varient ) |
| Shutter Speed | 1/60 to 1/4000 sec (Auto CCD Iris) , |
| Minimum Illumination | 3 lux (F1.2, AGC ON) |
| Sensitivity | 2000 lux @ F8, AGC OFF (0dB) |
| Gain Control | AGC (0 - 18dB)/Fixed (0 dB) |
| White Balance | AutoTrace, 3200K, 5600K &Manual |
| Video S/N | 40 dB |
| Temperature | Storage: - 53 to +100°C Operating: - 40 to 85°C |
| Humidity(non-condensing) | Storage: 20 - 90% Operating: 20 - 80% |
| Size | 35 x 35 x 85 mm |
| Mass | 100 g |
| Power | 5 V, 2.4 W |
| Mounting External | (fairing) |
| Mounting Internal | (bracket) |
| Monitoring | Environmental monitoring (optional Tech |
 |
|
